Geometry
| Size | 44cm | 49cm | 52cm | 54cm | 56cm | 58cm | 59cm | 61cm |
|---|---|---|---|---|---|---|---|---|
| Wheel Size | 700 | 700 | 700 | 700 | 700 | 700 | 700 | 700 |
| Stack | 491mm | 504mm | 517mm | 534mm | 555mm | 581mm | 568mm | 602mm |
| Reach | 369mm | 378mm | 383mm | 387mm | 398mm | 405mm | 413mm | 411mm |
| Head Angle | 70.5° | 71.75° | 72.5° | 73° | 73.5° | 73.5° | 73° | 73° |
| Seat Angle | 75.5° | 75.5° | 74° | 74° | 73.5° | 73.5° | 73.5° | 73° |
| Top Tube Length | 496mm | 509mm | 531mm | 541mm | 563mm | 577mm | 587mm | 595mm |
| Head Tube Length | 93mm | 102mm | 113mm | 131mm | 151mm | 178mm | 163mm | 198mm |
| Standover | 723mm | 735mm | 746mm | 768mm | 786mm | 808mm | 809mm | 834mm |
| Fork Trail | 71mm | 63mm | 58mm | 58mm | 55mm | 55mm | 55mm | 52mm |
| Fork Offset | 47mm | 47mm | 47mm | 44mm | 44mm | 44mm | 44mm | 44mm |
| Bottom Bracket Drop | 74mm | 74mm | 74mm | 72mm | 72mm | 72mm | 72mm | 72mm |
| Front Center | 572mm | 574mm | 577mm | 579mm | 592mm | 606mm | 610mm | 613mm |
| Wheelbase | 970mm | 973mm | 975mm | 978mm | 991mm | 1006mm | 1009mm | 1013mm |
| Chainstay Length | 410mm | 410mm | 410mm | 410mm | 410mm | 410mm | 410mm | 410mm |
